Platinum “R” Floor represents a leap forward in construction technology. Platinum “R” Floor is set to revolutionise the way we build, providing a sustainable, efficient, and high-performance plywood structural insulated panel flooring option for your next project. Experience the future of construction with Platinum Timber & Ply’s Platinum “R” Floor.

---

Key Features and Benefits

• Strong – Joist centres up to 800mm.
• Thermal Properties – 54mm Panel – R1.2, 64mm Panel – R1.5
• Time-Saving – Structural flooring and underfloor insulation are installed in one simple process from the top of the structure, with NO joist set down for wet areas.
• Environmentally Friendly – 100% Recyclable at end of use, reduced carbon emissions through a reduction in energy usage of the building.
• Sustainable – Manufactured from Australian sustainable grown plantation pine.
• Light Weight – Average weight 14kg/m2 (dependent on panel thickness)
• Cost Effective – Fewer joists required, time saved during installation, no underfloor insulation required.
• Easy to Install – As simple as installing a traditional sheet floor.
• Australian Made – All components are manufactured and assembled in Australia.
• Thermal Breaks – When using a steel joist system, there is normally a need for a barrier between the joist and the flooring. Platinum “R” Floor panels provide this thermal break without the need for additional material.
• Wet Area Set Down –Eliminates the need to notch out, set down or use different height joists to create the wet area. When installed, all that is required prior to waterproofing is a strip of fibre cement flashing between the edge of the flooring panel and the 19mm wet area flooring. This then gives an automatic step down to the wet area and allows to create a fall to the waste.
• Acoustic Properties – Significant reduction of sound.

Insulation and Energy Efficiency

The remarkable thermal performance of Platinum "R" Floor SIPS panels is one of their primary benefits. This structural insulated panel flooring solution improves home insulation, resulting in lower energy costs, better comfort, and a smaller environmental impact.


Acoustic Properties

A quieter living environment is produced by the significant sound reduction that this subfloor insulation helps to achieve between floors.


Construction Efficiency and Time/Cost Savings

In comparison to alternative sub-floor systems, Platinum "R" Floor SIP panels are lightweight, simple to cut using standard construction tools, simple to install, and require less manpower, which cuts down on installation time and related expenses. The long-term advantages drastically outweigh the initial cost, which may be marginally more than traditional building techniques. Fewer structural joists needed, and reduced construction timeframes, all contribute to significant cost savings.


Strength, Durability, and Customisation

Platinum "R" Floor is a robust and long-lasting flooring solution that is perfect for residential, commercial, and industrial settings since it can withstand heavy loads and impacts. In addition to being completely customisable on-site to fit any size or shape, Platinum "R" Floors surpass Australian Standard requirements, demonstrating that they are up to four times stronger than the load testing requirement. This makes them ideal for a wide range of applications, including prefabricated buildings, modular building projects, and cabins.


Sustainable Sourced and Proudly Australian-Made

Ensuring exceptional quality, all structural insulated panel components are created in Australia and constructed at the Platinum Timber & Ply warehouse in Brisbane. Platinum “R” Floor is made from radiata pine, a type of tree commonly found in Australia grown in plantations that are carefully managed to ensure the sustainability of the resource. The Responsible Wood Chain of Custody certification guarantees the legality and sustainability of our products, promoting responsible forest management. Manufactured in Australia and constructed in Brisbane, Platinum "R" Floor SIPS panels are a sustainable building material that can be recycled entirely after use.


---

Contact the team today on 07 4633 2411 or via admin@westsidetimbers.com.au to learn more.
